4.0 LED Indicator
This chapter provides the description of LED indicator on the mainboard which
controlled by BMC.
4.1 BMC Heartbeat LED
The BMC Heartbeat LED Indicator is used to indicate the BMC firmware
running status. The status behaviors are list below:
Table 1. BMC Heartbeat LED Status
Color
Status
Description
Green
Solid Off
⚫ System AC power off.
⚫ BMC firmware not running.
Solid On
⚫ System AC power on.
⚫ BMC firmware is initializing.
⚫ BMC firmware is updating firmware
image.
Slow Blinking (~1Hz)
⚫ BMC firmware is ready.
Fast Blinking (~4Hz)
⚫ BMC firmware is running in
manufacturing (MFG) mode.
4.2 UID LED
The UID (Unit Identification) LED Indicator is used to locate the particular
server system when it is deployed in the rack. It can help users to quickly
identify a server system for maintenance.
Table 2. UID LED Status
Color
Status
Description
Blue
Solid Off
⚫ Press the UID Button while UID LED
is turn on.
⚫ IPMI Chassis Identify command
“Turn Off Identify”.
Solid On
⚫ Press the UID Button while UID LED
is turn off.
