2.10.1 Remote Images
Remote Images page provides various options for users to view the configured
images on BMC.
To view the Remote Images page, click the Image Redirection -> Remote
Images tab from the menu bar.
Figure 116. Snapshot of Remote Images Page
The fields on the Remote Images page include
⚫ Media Type: The type Media devices supported for Active Redirections.
⚫ Media Instance: The number of Media devices supported for Active
Redirections.
⚫ Image Name: The name of Media devices supported image for Active
Redirections.
⚫ Redirection Status: The status Media for Active Redirections.
⚫ Connected Server Session Index: Indicates the number of connected
server session index.
⚫ Play: Click Play ( ) button to redirect the selected image.
⚫ Stop: Click Stop ( ) button to stop the remote image redirection.
⚫ Clear: Click Clear ( ) button to clear the selected image from the
BMC.
⚫ Refresh Image List: Click Refresh Image List ( ) to get the latest
list of Images from the Remote storage server.
