2 3
English
1.2 Specications
E3C256D4I-2T
Physical Status
Form Factor mini-ITX
Dimension 6.7" x 6.7"
Processor System
CPU Supports Intel® Xeon® E-2300 and 10
th
Gen Intel® Pentium®
series processors
Socket Single Socket H5 (LGA1200)
ermal Design
Power (TDP)
95W
Chipset Intel® C256
System Memory
Supported
DIMM Quantity
4 DIMM slots (2DPC)
Supported Type DDR4 288-pin ECC/non-ECC SODIMM
Max. Capacity
per DIMM
ECC/non-ECC SODIMM: up to 32GB
Max. Frequency ECC/non-ECC SODIMM: max. 2933MHz (1DPC) / max.
2133MHz (2DPC) [TBD]
Voltage 1.2V
PCIe Expansion Slots (SLOT7 close to CPU)
SLOT7 PCIe4.0* x16 [CPU]
Note *SLOT7 supports PCIe3.0 only when installing 10
th
Gen Intel® Pentium® Series
Processors
Other PCIe Expansion Connectors
M.2 slot 1 M-key* (PCIe4.0 x4); support 2280 form factor [CPU]
OCuLink 2 OCuLink (PCIe3.0 p10-x4 or 4 SATA 6Gb/s) [PCH]
Note *M.2 will not fuction when installing 10
th
Gen Intel® Pentium® Series Proces-
sors
SATA/SAS Storage
PCH Built-in
Storage
Intel® C256 (Up to 8 SATA 6Gb/s; RAID 0/1/5/10):
2 OCuLink
Ethernet
Additional
Ethernet
Controller
2 RJ45 (10GbE) by Intel® X550
USB
Connectors/
headers
External:
2 Type-A (USB3.2 Gen1)
Internal:
1 header (19-pin, 2 USB3.2 Gen1)
