14
Drain hose can also be connected directly to the
washbasin drain via a siphon. In this case, the hose,
too, should be 24" to 36" (610 mm to 914 mm) above
the fl oor. Internal hose diameter should be at least
0.71" (18 mm).
See fi gure.
At least 0.71" (18 mm)
If the hose is extended, the internal diameter of
the coupling must not be less than ½" (12.2 mm).
Do not extend the drain hose higher than 36"
(914 mm) from the bottom of the unit.
CONNECTING TO THE POWER MAINS
After installation, the washing machine should
stand still for two hours before it is connected to the
power mains.
Connect the appliance to a grounded power outlet.
After installation, the wall outlet should be freely
accessible. The outlet should be fi tted with a
grounded contact (in compliance with the relevant
regulations).
Electrical Connections
The machine is delivered ready-fi tted with a plug
and is intended for connection to an ASKO Dryer,
which is equipped with a matching receptacle. The
plug supplied with the washer can only be used with
an ASKO Dryer. If the washer is used separately or
with another dryer, it must be on a separate 208-240
V single-phase circuit.
If the machine is to be used in a wet area, the supply
must be protected by a residual current device.
As supplied: 208-240 V, 60 Hz, 2000W heating
element, 15A fuse required.
Connection to a permanently wired supply point
must be made only by a qualifi ed electrician.
