13
INSTALLING THE DRAIN HOSE
Upon delivery, the appliance has a drain hose
attached. This drain hose must be connected to
a drain. Drain hose can also be attached to a wall
drain with a trap; such trap should be properly
installed to allow cleaning. The height of the drain
should be 600–900 mm above the fl oor. The lower
position (600 mm) is always recommended. Make
sure the drain hose is not clipped or bent.
Use the supplied hose clamp if you connect the
drain hose according to option (B).
600 - 900 mm
600 - 900 mm
600 - 900 mm
B
C
A
Drain hose can also be connected directly to the
washbasin drain via a siphon. In this case, the hose,
should be 600–900 mm above the fl oor. Internal
hose diameter should be at least 18 mm.
See fi gure.
At least 18 mm
CONNECTING TO THE POWER MAINS
After installation, the washing machine should
stand still for two hours before it is connected to the
power mains.
Connect the appliance to an earthed power outlet.
After installation, the wall outlet should be freely
accessible. The outlet should be fi tted with an earth
contact (in compliance with the relevant regulations).
Connection upon delivery
TYPE: WMXX.XXXXX
Art.No.: XXXXXX/XX Ser.No.: XXXXXXXX
MODEL: XXXXXX.X
XXXX W
XXA
IPX4
X kg
XXX-XXX V ~
XX Hz
XX-X MPa
Information about your washing machine is indicated
on the rating (type) plate.
Use the type A diff erential current protection switch.
We recommend using over-voltage protection to
protect the appliance in case of a lightning strike.
The washing machine may not be connected to
the power mains using an extension cord.
Do not connect the washing machine to an
electrical outlet intended for an electric shaver or
hair dryer.
Any repair and maintenance pertaining to safety
or performance should be done by trained experts.
