12
How to stack a dryer onto the washing machine (ASKO):
There is a cardboard box in the dryer drum, containing the vacuum feet and the tipping guard.
A B
1
The tipping guard consists of two metal parts (A +
B).
Use two screws to attach the A part to the back of the
dryer.
2
Undo the screw on the back side of the washing
machine.
3
Use the screw to attach the tipping guard (B part)
to the back of the washing machine.
1
2
3
4
Level the washing machine so that it is stable.
1. Level the washing machine in longitudinal and
traverse direction by rotating the adjustable feet
using a No. 32 spanner.
The feet allow levelling by +/- 1 cm.
2. After adjusting the height of the feet, fi rmly
tighten the jam nuts (counter nuts) using a
spanner No 17, by turning them towards the
bottom of the washing machine .
3. Tighten the jam nuts (counter nuts).
5 mm
1
2
5
Set the dryer feet:
1. Tighten the front two feet all the way it in inner
position.
2. Undo the back feet by 3.5 turns or 5 mm; then,
fasten the jam nuts towards the bottom of the
appliance .
1
3
A
B
2
6
Place the dryer onto the washing machine:
1. Lift the front part of the dryer by 5 to 10 cm.
2. Attach the vacuum feet onto the front feet of the
dryer.
3. Push the dryer into the tipping guard (so that
the B part is inserted into the A part) and
release it (see the picture on previous page as
well).
Make sure the tipping guard is "locked"!
