5 Remove the connector from the lock.
Insert the connector into the rib of the plastic
housing to prevent the appliance from rattling
when the connector is not plugged in.
6 On the opposite side where the door has
come off, remove the connector from the rib,
pull it out of the appliance and connect it to
the door lock.
7 Place the door lock in the appliance in the
reverse order of its removal from the appliance.
Remount the door lock cover.
8 Undo the door hinge assembly (left) and
the door latch assembly (right), switch their
positions, and replace the screws (door hinge
assembly to the right-hand side, door latch
assembly to the left-hand side).
Use a screwdriver to remove the plastic part
more easily.
9 Install the door on the front wall and screw
it in.
Opening the Door
The tumble dryer door is designed to open on
the left side, with a visual indicator in the form
of a sticker placed on the front of the door,
clearly marking the spot for gripping and
opening.
1 In case of changing the door opening
direction, you can move the sticker to the
opposite side. Carefully remove the sticker
and attach it to the right side of the door,
ensuring it is positioned at the same height.
1
23
Installation and connection
