INFORMATION!
Incorrect levelling of the dryer with the adjustable legs may cause vibration, appliance sliding
across the room, and loud operation. Incorrect levelling of the dryer shall not be subject to
warranty.
INFORMATION!
Sometimes, unusual or louder noise may appear during appliance operation; these are mostly
the result of improper installation.
Installation under the counter
ASKO dryers can be installed under a furniture
unit or worktop which is at a height of at least
864 mm (measured from the floor to the bottom
surface of the counter). On all sides of the
appliance, there must be at least 12 mm of
room. Between the rear edge of the top panel
of the appliance and the wall behind the
appliance, the clearance must be at least
25 mm. The width of the opening in which you
want to insert the appliance must be at least
624 mm (measured between the sides that
limit the opening). The condenser models work
best when there is sufficient air circulation.
Install the dryer so the condensed water will continuously flow into a drain or sink, you will need a
drain outlet behind the unit. The maximum drain height is 1000 mm.
INFORMATION!
The height adjustment for the dryer is between 850 mm to 876 mm. Do not raise the appliance
higher than 876 mm.
It is very important to avoid a buildup of heat.
The warm air which is expelled from the rear of the dryer must be able to dissipate.
Warm air which cannot dissipate could cause a fault.
A buildup of heat could be avoided by:
• Creating a gap for the dryer in the kitchen furniture plinth facing.
• Creating ventilation gaps in the kitchen unit.
When build under, drying times may be longer.
16
