NOTE!
The surface to which the protective film is affixed must be clean and dry.
Adjust the height and slide the dishwasher into place
1. Start by measuring the height from the floor to the bottom edge of the worktop.
2. Measure the height from the floor to the top edge of the dishwasher.
3. Lean the dishwasher forwards a little and adjust the rear foot with the screw at the front of the
dishwasher. Turn clockwise to lower or anticlockwise to raise.
4. Adjust the front feet by turning them clockwise to raise and anticlockwise to lower the dishwasher.
24 mm
16 mm
5. Check that there is an air gap of at least 3 mm between the underside of the worktop and the
top edge of the dishwasher.
6. Slide the dishwasher into place.
• Pull the supply and drainage hoses and the power cable when sliding the dishwasher into
place.
44
Installation
