• Programs: Anti odour, Flexi AU, Preheated, Self cleaning, Quick Pro wash,
Crystal glass, Lower half, Upper half, Rinse and hold programme, Heavy
wash, Time program, Hygiene wash, ECO wash, Auto wash, Intensive
program
• Main wash temperature (°C): 45/50/55/60/65/70
• Delayed start: Possible to delay up to 24 hours
• Options and modes: Enable/disable automatic door opening, Super Rinse™
- Two extra rinses, Time set, Green mode - Less energy and water is used.
The program time is extended, Speed mode - The program time is shortened.
More energy is used., Night mode - Lower noise level. The program time is
extended., Intensive mode - The dishwasher uses more heat and water. The
program time is extended, ExtraHygiene with UV Technology, Sensor
controlled door opening - Optimizes the drying process according to the
room temperature, Light sabbath mode
Design and integration
• From the front adjustable door spring: No
• From front adjustable rear foot: Yes
• Installation: Integrated anti-siphon - Prevents spontaneous in- and outlet of
water and simplifies elevated installation, Steam protection strip
• Sliding door: No
• Possible to install elevated: Yes
• Min. niche width: 600 mm
• Min. niche height: 860 mm
• Depth (incl. wall spacing): 555 mm
• Max Height adjustment: 53 mm
• Adjustable kick plate: 30-94/0
Safety and maintenance
• Aqua Safe™ system: Anti Block™ - Self cleaning drain pump, Light and
sound alarm, Maximum time for water intake, Extra durable PEX inlet hose,
Stand-by water protecion - Leakage detection when machine is off, Aqua
Level™ Sensor - Ensures an optimized water level, Aqua Detect™ - Instant
recognition of any leakage in the motor compartment, Detection of water
leakage on the bottom plate, Waterproof bottom plate, Extra durable stainless
steel container, Sealing points outside container
• Aqua Safe™ system: Yes
• Child safety: Kid Safe™ - Lockable controls
• Indication of low level of rinse-aid: Notification in display
Technical data
• Water connection: Size 3/4" - Can be connected to cold water
• Adapter for water connection: No
• Max. temperature of inflow water: 70 °C
• Noise level (max): 39 dB(A)
• Reference programme: 1
• Duration of standard programme: 178 min
• Estimated yearly energy consumption: 216 kWh
• Energy consumption - normal program: 0.571 kWh
• Energy stars: 4.5
• Water stars: 6
• Water consumption: 10.6 l
• Power consumption in standby mode: 0.77 W
• Plug type: AU plug
• Connected load: 2000 W
• Voltage (V): 220-240 V
• Number of phases: 1
• Fuse: 10 A
• Frequency: 50 Hz
• Required inlet water pressure MPa: 0,03-1
• Net weight: 43 kg
Dimensions
• Width: 596 mm
• Height: 859 mm
• Depth: 554 mm
• Maximum product height: 912 mm
• Length of electrical cord: 1730 mm
• Depth with door open: 1231 mm
