Je bekijkt pagina 39 van 48
Adjust the height and slide the dishwasher into place
1. Start by measuring the height from the floor to the bottom edge of the countertop.
2. Measure the height from the floor to the top edge of the dishwasher.
3. Lean the dishwasher forward a little and adjust the rear foot with the screw at the front of the
dishwasher. Turn clockwise to lower or counterclockwise to raise.
4. Adjust the front feet by turning them clockwise to raise and counterclockwise to lower the
dishwasher.
5. Verify there is an air gap of at least 1/8'' between the underside of the countertop and the top
edge of the dishwasher.
6. Slide the dishwasher into place.
Pull the inlet and drain hoses and the supply cord when sliding the dishwasher into place.
Check that the drain hose has no kinks or sharp bends. Also check that there is nothing that
can damage the hoses.
Check that the machine is installed such that the door opens freely, otherwise door lock
functionality may be disrupted.
7. Make any final adjustments to the front feet.
Drain connection
This dishwasher is suitable for installing in a raised recess (to obtain an ergonomic working height).
This means that the dishwasher can be placed so that the drain hose runs to a lower level than the
bottom of the dishwasher, such as by routing it directly to a floor drain.
39
Installation instructions
