33 3/4 - 35 11/16 (856-906)
21 7/8 (555)
29 3/4 (754)
23 13/16 (605)
4 15/16 (125)
2 1/8 (53) 4 1/4 (108)
48 1/2 (1232)
29 1/4 (742)
20 7/16 (519)
1 7/16 - 3 5/8 (35-92)
Nominal dimensions. Actual measurements may vary.
Inches (mm)
Important safety instructions
• Connections to electricity, water, and drain must be performed by a qualified professional.
• Always follow applicable regulations for water, drainage, and electricity.
• Take care during installation! Wear protective gloves! There must always be two people!
• Place a drip tray on the floor beneath the dishwasher to prevent damage from any water leaks.
• Before fastening the dishwasher, test the dishwasher by running the Rinse and hold program.
Check that the dishwasher fills with water and drains. Check also that none of the connections
leak.
WARNING!
Turn off the water supply when installing the dishwasher!
The plug must be disconnected or power to the outlet turned off while installing the dishwasher!
NOTE!
A integrated door panel must not be fitted to the dishwasher.
Placing the dishwasher
The dishwasher is intended to be built-in under a countertop. Make sure that the edges of the hole
are even and will not damage the drainage and inlet hoses or the supply cord.
37
Installation instructions
