Je bekijkt pagina 4 van 36
Operating Manual - digiMIX24 Digital Mixer
4
1 INTRODUCTION
Thank you for purchasing the Ashly digiMIX24 digital and networkable 24 input x 14 bus mixer. This owner's manual
corresponds to digiMIX24 mixers with installed rmware version v5.0 or higher. v5.0 rmware added digital audio insert
capability (sec. 7), and separated the rmware update utility from the preset update utility (sec. 6).
With 16 high performance discrete mic/line preampliers, assignable auto-mixer, 4 line-level inputs, stereo tape inputs, stereo
USB audio input, assignable cross-fade mode, DSP processing with parametric and graphic EQ, compressor/limiter, expander/
gate, delay, invert polarity, two built in stereo effects buses, four aux buses, four subgroups which can switch to four additional
aux outputs, six DCA groups, sensitive LED metering, preset control, password security, iPad
®
remote control via network con-
nection, and much more, the compact and powerful digiMIX24 offers all the right tools to manage your sound job with condence.
In order to thoroughly understand the features of the digiMIX24, please read this entire manual as you explore the controls,
touchscreen, and remote control capabilities of your mixer.
Standard Features:
• 7 inch color LCD touch screen for graphical viewing, assign, and setup
• Wired network interface for Ashly digiMIX24 iPad remote control app, available free on the App Store
®
• 16 low noise mic/line preamps with Neutrik Combo jacks, dedicated trim controls, +48V phantom power, phase invert
• 4 aux sends and 4 subgroup outputs, switchable to 8 aux sends
• 6 DCA for fader or mute groups
• Cross-fade mode for panning between any two assigned channels
• Stereo link for inputs, subgroups, and aux outputs
• EZ-Mode for secure, simplied touchscreen or iPad
®
control
• TRS inserts on channels 1-8
• Digital inserts on channels 1-16 with optional Dante-32 or USB-32 module installed
• 2 internal stereo FX with fully editable reverbs, delay with tap tempo, tremolo, anger, and chorus.
• Automixer (gain sharing), individually assignable to input channels 1-16
• Four additional line-level inputs on 1/4" jacks
• Stereo RCA inputs and outputs
• USB 2-track audio stereo record and playback
• 100mm precision Alps
®
motorized fader
• Pan control
• High resolution delay (0.2mS) on every input, subgroup, aux, or FX
• Expander/noise gate on every input and FX channel
• Compressor/limiter on every input, subgroup, output, and FX channel
• 4-band parametric/shelving EQ lters plus HPF/LPF on every input, subgroup, output, and FX channel
• 31-band graphic EQ on main, aux, and sub outputs
• Solo/PFL on every input, output, subgroup, aux, or FX
• Stereo main output on XLR and 1/4" phone jack with dedicated level control
• Headphone and control room outputs with level control
• User presets for Scene Settings, DSP channel settings, FX settings, or GEQ settings, plus channel copy function
• 32-bit A/D and D/A converters, 32-bit DSP processing, 48KHz sampling rate
• Password security
• Utility programs for rmware update and preset backup/restore (Windows
®
or Mac
®)
• Internal 100-240VAC universal power supply
• Safety/compliance: cTUVus, CE, FCC, RoHs
Optional Features
• Dante-32 network audio interface, eld installable, digital outputs for input channels 1-16 are selectable pre/post DSP
• USB-32 multi-track audio interface, eld installable, digital outputs for input channels 1-16 are selectable pre/post DSP
