Replacement and maintenance
Control Panel
Replacing lamp
If the supply cord is damaged, it must be replaced by the manufacturer its service agent or similarly qualified persons in order to avoid a hazard.
1.Disconnect the electrical plug.
2.Use the“ ”type screwdriver to remove the damaged lamp from lamp hole.
3.Disconnect the connectors between damaged lamp and lamp wire.
4.Connect the connectors between new lamp and lamp wire. Put the lamp click into place of lamp hole.
Warning: Lamp replacement must be done by qualified after-sales service maintenance personnel.
Required min. distance to surfaces (such as lids, oven cloth or the like) in order to prevent hot parts and fire hazards.
Only self shielded lamps can be used in order to prevent undue hot parts, fire hazards and exposure to UV radiation.
Information: Do not touch the light bulb within half an hour after appliance use. The lamp shall not be covered with thermal
insulation or other material.
- Put the outer chimney and inner chimney together on the windshield (Fig.12).
- According to the dimension of the chimney fixed bolster, make sure the position of the two chimneys (Fig.13).
Information: Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and
standards, including fire-rated construction.
Install the chimney fixed bolster on the corresponding position on the wall (Fig.14).
- Use the Screw ST4*8 to connect the chimney fixed bolster and the upper chimney (Fig.15).
Information: To install this hood you will require two assistants.
Cleaning grease filters
Correct Disposal of this product
It is recommendable to clean the metallic filter every three months b
y carrying out the following instructions (Fig.16):
- Remove the metallic filter from the cooker hood and wash it in a solution of water and neutral liquid detergent, leaving to soak
- Rinse thoroughly with warm water and leave to dry.
- The metallic filter may also be washed in the dishwasher. The metallic filter may alter in color after several washes. This is not cause for
customer complaint nor replacement of metallic filter.
Information: There is a fire risk if cleaning is not carried out in accor
Information: The power of bulb must not be more than 2W .
dance with the instructions.
Press the button and the hood will go into standby mode.
Press the button and the fan speed will change: Low - Med - High - Stop.
Press the button and the fan speed will change: High - Med - Low - Stop.
Press the light button to turn on the lights and press again to turn off the lights.
the hood between 1 and 9 minutes after use. Press the button to exit. between
When the button is turned on, long press the button for 3 seconds to set the clock, press or to set the time.
When the motor run, you can press the button to set the time-off, then press the button and the button to set the timer to turn off
12V 2X2W Max
(- - - to be "0 45 m”)
The manufacturer shall decline all responsibility if the foregoing recommendations and instruction
regarding installation, maintenance and use are not observed and respected when using the cooker hood.
This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this product for environmental safe recycling.
