EN - 16
maximum power, in which case the
integrated power management will be
activated.
The necessary power reduction is shown
by the corresponding cooking zone display
blinking. Blinking will be active for 3
seconds to allow for further adaptations of
the settings before power reduction.
Error Codes
If there is an error, an error code will be shown on the
heater displays.
E0
Ampere limit feature must be selected at the
moment the product is energized. Otherwise
E0 error is seen. At the same time, this
feature should be selected on the display
and mainboard. If there is an error in the
software of any card, the product will show
an error. The customer cannot interfere
in this error. Authorized service should be
called.
E1
Cooling Fan is disabled. Call an authorised
service agent.
E2
This error is seen when the heater gets too
hot. In case of this error, the heater must be
cooled. It should be operated after cooling,
again.
E3
Supply voltage is other than the rated values.
Switch the hob off by pressing ,wait until
“H” disappears for all zones, switch the hob
on by pressing and continue to use. If
the same error is displayed again, call an
authorised service agent.
E4
Supply frequency is different from the rated
values. Switch the hob off by pressing
, wait until “H” disappears from all
zones, switch the hob on by pressing
and continue to use. If the same error is
displayed again, switch the plug for the
appliance off and on. Switch the hob on by
pressing and continue to use. If the same
error is displayed again, call an authorised
service agent.
E5
Internal temperature of the hob is too high,
switch the hob off by pressing and let the
heaters cool down.
E6
Communication error between the touch
control and heater. Call an authorised service
agent.
E7
Coil temperature sensor is disabled. Call an
authorized service agent.
E8
Cooler temperature sensor is disabled. Call
an authorized service agent.
EA
Large Coil Saturation Error. Switch the hob
off by pressing on/off button, switch the hob
on by pressing on/off button and continue to
use. If the same error is displayed again, call
an authorised service agent.
EC
Supply Voltage Error.Switch the hob off by
pressing on/off button, switch the hob on by
pressing on/off button and continue to use.
If the same error is displayed again, call an
authorised service agent.
C1-C8
Microprocessor alert. After this warning,
cut off energy from the product and then
re-energize the product. If the same error is
displayed again, call an authorised service
agent.
4.2 oven ControlS
Oven function control knob
Turn the knob to the corresponding symbol
of the desired cooking function. For the
details of different functions see ´Oven
Functions`.
Oven thermostat knob
After selecting a cooking function, turn
this knob to set the desired temperature.
The oven thermostat light will illuminate
whenever the thermostat is in operation
to heat up the oven or maintain the
temperature.
Oven Functions
* The functions of your oven may be
different due to the model of your product.
Oven Lamp: Only the
oven light will switch
on. It will remain on for
the duration of the
cooking function.
Defrost Function: The
oven’s warning lights
will switch on and the
fan will start to operate.
To use the defrost
function, place your
frozen food in the oven
on a shelf in the third slot from the bottom.
It is recommended that you place an oven
tray under the defrosting food to catch the
water accumulated due to melting ice. This
function will not cook or bake your food, it
will only help to defrost it.
Turbo Function: The
oven’s thermostat and
warning lights will
switch on, and the ring
heating element and
fan will start operating.
The turbo function
evenly disperses the heat in the oven so all
food on all racks will cook evenly. It is
recommended that you preheat the oven for
about 10 minutes.
