Protocol
54
SkyPanel-C
From Firmware-Version 2.5 - Overview
GN saturation - average equivalents.
Mode 1: CCT & RGBW, 8 bit Resolution per Function
8 bit, 1 channel
per function
16 bit, 2 chan-
nels per function
Coarse/fine, 1-2 chan-
nels per function
Mode 1
CCT & RGBW
Mode 6
CCT & RGBW
Mode 11
CCT & RGBW
Mode 2
CCT
Mode 7
CCT
Mode 12
CCT
Mode 3
CCT & HSI
Mode 8
CCT & HSI
Mode 13
CCT & HSI
Mode 4
RGBW
Mode 9
RGBW
Mode 14
RGBW
Mode 5
HSI
Mode 10
HSI
Mode 15
HSI
Mode 16
GEL V2
Mode 17
GEL V2
Mode 18
xy coordinates
Mode 19
xy coordinates
Setting Rosco# Setting Rosco#
Full -Green 3308 Full +Green 3304
1/2 -Green 3313 1/2 +Green 3315
1/4 -Green 3314 1/4 +Green 3316
1/8 -Green 3318 1/8 +Green 3317
Channel Value Percent Function
1
0-255 0-100
Master Intensity
0 % 100% (open)
2
0-255 0-100
Color temperature CCT
2.800 K 10.000 K
3
0-10
11-20
21-119
120-145
146-244
245-255
0-4
5-8
8-46
47-57
57-96
96-100
GN saturation
neutral / no effect
full minus green
-99% -1%
neutral / no effect
1% 99%
full plus green
4
0-255 0-100
Xfade to color
White RGBW color
5
0-255 0-100
Intensity red
0% 100%
6
0-255 0-100
Intensity green
0% 100%
7
0-255 0-100
Intensity blue
0% 100%
8
0-255 0-100
Intensity white
0% 100%
9
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
10-12 Reserved (only V4.x)
