Fixture Menu
33
Master/Slave Mode
In Master/Slave mode the slave fixtures mimic the master fix-
ture without delay. The master fixture generates a DMX signal
on the 5-pin DMX Thru connector.
Connect a maximum of 32 SkyPanels and L-series fixtures to
a DMX data link. Choose one SkyPanel to be the master fix-
ture.
Warning! There must not be more than one SkyPanel in the
data link set to master. Setting more than one fixture to master
or connecting a DMX controller to the data link causes one or
all master fixtures to de-activate the master mode and display
an error message (error 25).
To set the master fixture:
• Press the MENU button (10) to open the fixture menu.
• Turn I/S, until „Light Control“ is displayed. Press I/S to open
the menu.
• Turn I/S, until „Master/Slave Mode“ is displayed. Press I/S to
open the menu.
• Set all fixtures in the data link to „Off“ to de-activate master
mode. Select „On“ on one fixture in the data link to set the fix-
ture as master fixture.
• Press MENU to close the menu.
All fixtures in the data link will mimic the master fixture automat-
ically and independent from their settings.
Please note when using the master/slave mode:
• Art-Net is de-activated on all fixtures in the data link.
• Changing the mode on the master fixture (CCT, HSI, GEL)
changes the mode on all slave fixtures accordingly.
• The settings DMX protocol version, DMX address, tungsten
mode, low end mode, fans and signal loss behavior are
changed accordingly to the settings of the master fixture.
• Connect only C version fixtures of one type in a data link.
• L-series fixtures do not support the GEL mode.
• Presets are not available.
• The party mode is not available.
To set the DMX address
• Press the MENU button (10) to open the fixture menu.
• Turn I/S, until „DMX Settings“ is displayed. Press I/S to open
the menu.
• Turn I/S, until „DMX Address“ is displayed. Press I/S to open
the menu.
• Select the DMX address by turning I/S. Press I/S to confirm
the setting.
• The menu „DMX Address“ closes automatically. Press the
MENU button to force closing the menu.
To set the DMX Protocol
• Press the MENU button (10) to open the fixture menu.
