9
Fixture MenuFixture Menu
9
To store a DMX preset
A long (> 3 sec.) simultaneously press of the MENU and PRESET button opens the DMX preset list. Turn
the encoder (4) to select one of 10 DMX presets. Select a slot and press the encoder (4) to store the DMX
preset. BACK (11) returns to the main screen.
MODE (8)
Press the MODE button short to swap between CCT, HSI, GEL, Source Matching, RGBW mode and x,y
mode of the SkyPanel.
Press the MODE button long (> 3 sec.) to activate the extended color control. The extended color control
feature is not available in RGBW mode unless RGBW Calibrated Color Space is activated.
DISPLAY (9)
The display shows the current settings and other information during normal operation. Press the MENU
button (10) to open or close the fixture menu. Use the encoder (4) and the BACK button (11) to navigate
through the fixture menu.
MENU (10)
The MENU button opens the fixture menu. Press MENU when the fixture menu is open to close the menu
and abort an action (Escape). Use the encoder (4) to scroll through the menu, open sub menus and set
parameters.
Press MENU long to display the menus which are used most.
BACK (11)
The BACK button closes a sub menu and aborts an action (Escape). Compared to the MENU button (10)
the BACK button only closes the sub menu, but not the fixture menu.
Press BACK long to display the last used menus.
To lock the fixture menu
• Press the encoder in the home screen for 5 seconds to lock all buttons and knobs. Use the feature to
prevent an accidental change of settings.
• The word LOCKED appears on the display when locked.
• Press the encoder in the home screen for 5 seconds again to unlock all buttons and knobs.
• Please find a overview in chapter Overview of the Fixture Menu on page 35.
To Set the Operation Mode
Press the MODE button (8) short to switch from CCT to HSI to GEL to Source to RGBW to x,y and back to
CCT mode.
In CCT mode the SkyPanel generates white light with optimized color rendition. In HSI mode the SkyPanel
generates colored light. If saturation is set very low, the SkyPanel generates white light, but not with
optimized color rendition. The GEL mode offers an extensive color gel library. In Source mode the
SkyPanel generates the light of traditional light sources. Use the RGBW mode to generate a RGBW color
using the control panel. The x,y mode generates a color defined by its x,y coordinates.
Press the MODE button long (> 3 sec.) to activate the extended color control. The extended color control
feature is not available in RGBW mode unless RGBW Calibrated Color Space is activated.
