Fixture Menu
8
STATUS-LED (3)
Display Backlight
Encoder (4)
The encoder (4) has two functions:
• Fixture menu closed: Setting the intensity.
• Fixture menu open: Use the encoder to scroll through the menu, open sub menus and set parameters.
Pressing the knob opens sub menus and confirms settings.
Central Rotary Knob (5)
Use the rotary knob to set the color temperature (CCT) or the color hue (HUE). The current function of the
rotary knob is shown in the display (9) above the knob.
Right Rotary Knob (6)
Use the rotary knob to set the green/magenta point or the color saturation (SAT) or, dependent on the
active color mode, categories or parameters. The current function of the rotary knob is shown in the display
(9) above the knob.
PRESET (7)
To call up a light preset
A short press of the PRESET button brings up the list of all available presets. Turn the encoder (4) to select
one of 10 factory presets and 10 user definable presets. Press the encoder (4) to activate the preset.
To store a light preset
Use the fixture menu to adjust the settings. Hold PRESET, until the preset save dialog opens. Turn the
encoder (4) to select a preset memory slot. Press the encoder (4) to store the preset. Close the dialog with
BACK.
To call up a DMX preset
A short simultaneously press of the MENU and PRESET button brings up the list of all available DMX
presets. Turn the encoder (4) to select one of 10 DMX presets. Press the encoder (4) twice to activate the
preset.
Color Indication
Green No error. Normal temperature.
Red flashing (0,5s rhythm)*
Warning fixture over temperature (only
with fan modes QUIET and HIGH).
Red
Error detected. An error message
appears in the display.
Calibration data not loaded.
Color Indication
Blue or Off No error, normal condition.
Red
The display lights up red when the
STATUS LED lights up red (error mes-
sage).
Orange
The display lights up orange when the
POWER LED lights up red.
