Error Codes
40
Error Codes
Code Error Remedy
E.003
Controller over temperature.
STATUS LED lit up red.
Let the SkyPanel cool down.Turn the dimmer knob to „0“ or
send an intensity value „0“ via DMX to activate the light
engine again.
E.004 Light engine over temperature
See E.003
E.005 Missing LED supply.
The LED power supply is faulty. Contact the ARRI service.
E.006
Calibration data of light engine
faulty or EEPROM error.
WARNING: Loss of calibration data. This error can only be
fixed by re-calibrating the light engine. Please contact the
ARRI service.
E.007 Invalid PWM value calculation
Notice: The SkyPanel can be used on. This message is more
a notification than an error.
E.008 Invalid values during calculation
See E.007
E.009 Invalid values during calculation
See E.007
E.010
Fan error. The fan speed devi-
ates or the fan doesn’t run at all.
All mechanical tests or repairs may only be carried out by a
trained service technician.
E.011
Fixture menu module not be
detected.
If the fixture menu is working, error E.011 can be ignored.
However, if the fixture menu remains dark (no LED lights up)
we recommend to contact the ARRI service. They can then
carry out detailed analyses.
E.012
Temperature sensor(s) are
defective or deviation within
NTC values too high.
One or more temperature sensors are defective or the devia-
tion within the individual NTCs or BNTCs exceeds the varia-
tion tolerance of 12° C / 54° F.
E.013 Calibration data faulty.
WARNING: Loss of calibration data. Fixture needs to be re-
calibrated.
E.014 Watchdog error
Notice: The SkyPanel can be used on. This message is more
a notification than an error.
E.015 LED channel faulty
Notice: The SkyPanel can be used on. This message is more
a notification than an error.
E.016 Boost over temperature
Let the SkyPanel cool down. Turn the dimmer knob to „0“ or
send an intensity value „0“ via DMX to activate the light
engine again.
E.018 PWM driver not found
Switch the SkyPanel off and on again. If the problem per-
sists, please contact the ARRI service.
E.019 Diffuser removed
The diffusor was removed. The protection circuit is active
(only RP-version).
E.020 Update with errors
This will be seen if the update process has detected an error
during the update.
E.021
Flash init error. No filesystem
mounted.
This will happen if the flash disc has a problem with its file
system.
E.022 Missing Boost
Switch the SkyPanel off and on again. If the problem per-
sists, please contact the ARRI service.
E.023 12V Missing
The 12V power is missing during startup. Please contact the
ARRI service.
E.024 5V Missing
The 5V power is missing during startup. Please contact the
ARRI service.
E.025 DMX Data Collision
The fixture detected data on the data line when trying to send
data as a gateway or host fixture. It deactivates the gateway
and/or host/client mode to avoid further data collision.
E.026 USB Drive not Mountable
USB stick can not be mounted. Remove the USB stick, wait
some seconds and reconnect it. If the problem persists, try
another USB stick.
E.027 S360-C Client missing
S360-C Client controller not detected. Power cycle the S360-
C. If the problem persists, please contact your ARRI service
partner.
E.028 Light Engine Missing
One or more light engines not detected. Increase the inten-
sity a little to identify the light engine not working. Check the
cable connection of the light engine. If the problem persists,
please contact your ARRI service partner.
E.029
DMX JSON Configuration miss-
ing or error by loading
Configuration error. Perform a firmware update.
E.030
New / Old error, only old or new
SPD2 and LE allowed
Certain revisions of drivers and light engines are not compat-
ible. Please let the component revisions be checked by your
ARRI service partner.
E.031
Problem by Setting Fixture
Factory Default
Factory default load error. Default data corrupted. Perform a
firmware update or contact your ARRI service partner.
