Overview of the Fixture MenuOverview of the Fixture Menu
35
Overview of the Fixture Menu
From Firmware-Version 4.4
Open and close the fixture menu the MENU button. BACK closes a sub menu and aborts an action.
Turn the encoder to scroll. Press the encoder to select an item
Level 1 Level 2 Level 3 Level 4 Explanation (default setting = bold)
DMX Set-
tings
DMX Address 001 - 512 Start address
DMX Mode P1 - P31 DMX Mode
DMX Loss
Behavior
Hold Last Command Fixture holds the last received control values
Black Out Fixture douses the dimmer
Hold 2 Min Fade Out
Hold the last received values for 2 min. then
douse
DMX Protocol
Version
Version 3.4
Version of the DMX protocol
Version 4.0
Version 4.1
Version 4.2
Version 4.3
Version 4.4
Ext. Color Control
Off DMX Extended color control not active
On DMX Extended color control active
RDM State
On RDM communication active
Off RDM communication not active
DMX Frame Filter
Off DMX Frame Filter not active
On DMX Frame Filter active
CRMX Settings
(only S360-C)
CRMX Data State
Off CRMX deactivated
On CRMX activated
CRMX
Connection
Linking
Key
Enter Linking Key with Encoder, middle and
right rotary knob. Press encoder on most right
position to proceed to next screen.
CRMX
Mode
Enter CRMX mode (Classic or CRMX2). Press
encoder to proceed to next screen.
CRMX
Output
Enter CRMX Output. Press encoder to estab-
lish CRMX connection.
Fan Mode
Normal (only S360-C) Fans temperature regulated
Quiet Mode Fan speed low
Variable Fans temperature regulated
High Temp Fan speed high
Light Mode
CCT
White light, color temperature and green /
magenta correction adjustable
HSI Colored light, hue and saturation adjustable
Gel
GEL mode, gel library available, color tempera-
ture 3.200 K or 5.600 K
Source Matching The SkyPanel emulates a specific light source.
RGBW Color mixing in RGBW mode.
x,y Coord. Setting the color via its x,y coordinates
