Functions
18
To set the frequency
1.Press the MENU button (10) to open the fixture menu.
2.Turn the encoder, until Light Control is displayed. Press the encoder to open the menu.
3.Turn the encoder, until Frequency Selection is displayed. Press the encoder to open the menu.
4.Select a frequency. Press the encoder to confirm the setting. The frequency is set immediately.
5. Press MENU to close the menu.
To set the Fan Mode
You can set the fan mode to adapt the cooling and noise level to the environment. The table below shows
the available options:
To set the Fan Mode
1.Press the MENU button (10) to open the fixture menu.
2.Turn the encoder, until Fan Mode is displayed. Press the encoder to open the menu.
3.Select the Fan mode by turning the encoder. Press the encoder to confirm the setting.
4.Press MENU to close the menu.
Lighting Effects
The SkyPanel offers an effect library with a wide variety of lighting effects used on set or in a TV studio.
The SkyPanel replaces many special effect devices with its unique effect library.
You can call up all effects using the fixture menu or via DMX, Art-Net or sACN. Every effect offers specific
parameters. A lighting effect can be stored in a preset slot for quick access at a later point.
To select and activate an effect
1.Press the MENU button (10) to open the fixture menu.
2.Turn the encoder, until Lighting Effects is displayed. Press the encoder to open the menu.
3.Select the desired effect by turning the encoder.
4.Press the encoder to start the effect.
5.Set the parameters, as described below.
To stop an effect
1.Press the MENU button (10) to open the fixture menu.
2.Turn the encoder, until Lighting Effects is displayed. Press the encoder to open the menu.
3.Select the option Off. Press the encoder to confirm.
Start / Stop function of the effect
If an effect is running, press the encoder to stop the effect execution. Press the encoder again to restart
the effect from the beginning. While stopped, the SkyPanel performs a black out and a P:<Effect> shows
the status in the display. The start / stop function is only available in the effects control screen.
The SkyPanel provides the following effects in DMX modes 22 (8 bit) and 23 (16 bit):
Party
The Party effect calls up the color spectrum or changes the color temperature from warm to cold and vice
versa in an endless loop.
Parameters:
• Saturation
• Speed
If you do not need the effect for shooting, you will need it for the party when the movie is done!
Fan Mode
Max. power
(only S360-C)
Description
Normal (only S360-C) 1500 W
The fans operate temperature regulated.
Quiet Mode 1200 W
The fans operate constantly at low speed
(silent).
Variable 1200 W
The fans operate temperature regulated.
High Temp 1200 W
The fans run at maximum speed.
