13
FunctionsFunctions
13
Functions
To set the Lighting Parameters in CCT Mode
Set the color temperature continuously with the central rotary knob (5). Set the green/magenta point
continuously with the right rotary knob (6). The current setting is displayed above the rotary knobs.
To set the Color in HSI Mode
Set the hue continuously with the central rotary knob (5). Set the saturation continuously with the right
rotary knob (6). The current setting is displayed above the rotary knobs.
To set the Lighting Parameters in GEL Mode
Use the central rotary knob (5) to set the color temperature 3.200 K or 5.600 K. The right rotary knob (6)
offers two options: Best color displays the gel with optimized color quality, Brightest displays the gel with
optimized brightness.
• Press the encoder (4) to open the gel library. Choose the gel manufacturer (Rosco or LEE) with the central
rotary knob (5). Use the right rotary knob (6) to activate a gel category as shown in the table below.
• Turn the encoder (4) to call up a gel from the gel set. Press the encoder to select a gel or press BACK
(11) to close the gel set and set the intensity with the encoder (4). Press the encoder (4) again, to re-open
the gel set.
To set the Light Source in Source Mode
Activate the source mode and press the encoder to call up a list of the light sources available. Use the right
rotary knob (6) to select the category (please see DMX protocol specification, which is available for free
download for a detailed list). Turn the encoder to select a light source. The SkyPanel calls up the selected
light source in real time. Press the encoder to choose the selected light source.
To set the Color in RGBW Mode
The central rotary knob (5) has no function in RGBW mode. Use the right rotary knob (6) to select the
functionality of the encoder I/S (4). Dependent on the selection of the right rotary knob, the encoder is used
to set the overall intensity of the red, green, blue and white color. Please note the setting Direct Control or
RGBW Color Space (see page 17). You can store the RGBW color as a preset.
To set the Color in x,y Mode
The x,y mode defines the color using its x,y coordinates. use the right rotary knob (6) to select the
functionality of the encoder (4). Dependent on the selection of the right rotary knob, the encoder is used to
set the intensity, the x or y coordinate of the color. The range of both the x and y coordinate is 0.0000 to
0.8000.
Extended Color Control
The extended color control allows the modification of the selected color in an intuitive way. It can be used
both via the control panel or DMX (see To Use the Extended Color Control via DMX on page 28).
Rosco LEE
Color Correction Color Correction
CalColor Color Filters
Storaro Selection 600 Series
Cinelux Cosmetic
700 Series
