Fixture ModesFixture Modes
11
Fixture Modes
The SkyPanel offers, depending on the model, up to 31 control modes. Use the 8 bit modes with basic
controllers like simple fader consoles.
ARRI recommends the use of the 16 bit modes in combination with controllers supporting 16 bit resolution
to obtain best results. The high resolution provides smooth dimming and precise color adjustments.
The coarse / fine modes utilize two channels for most parameters and provide higher resolution compared
to the 8 bit modes in combination with controllers that do not support true 16 bit resolution. One channel
sets the coarse value between 0 and 255 of the function. Each step is divided in 256 increments using the
fine channel. This way it is possible to control the light very precise without using a true 16 bit resolution.
Below is a short overview of the different control modes. Please find a detailed overview of all DMX modes
in the document SkyPanel DMX Protocol Specification which is available for free download on the ARRI
website www.arri.com.
CCT and RGBW
This mode provides control of intensity, color temperature, green/magenta point and individual channels
for controlling the red, green, blue and white color (only SkyPanel-C).
CCT
Simple white-only mode. It is used when the number of available channels of the controller is very limited.
It provides control of intensity, color temperature and green/magenta point.
CCT & HSI
Provides control of intensity, color temperature, green/magenta point, hue and saturation (HSI = hue,
saturation, intensity). In HSI mode (only SkyPanel-C) the color and intensity is very even over the fixtures
as it is controlled using color algorithms which take the tolerances of the light engines into account during
calculation.
RGBW
Simple mode for controlling the overall intensity and the red, green, blue and white intensity when only a
limited number of channels is available. Please find more information about the RGB color space on
page 17.
HSI
Simple mode for controlling hue, saturation and intensity when a limited number of channels is available.
GEL
The GEL mode offers an extensive color filter list. The color temperature has two settings, 3.200 K and
5.600 K. The intensity can be controlled as usual.
x,y Coordinates
The x,y mode determines the color displayed by its xy coordinates in the CIE 1931 diagram. Set the x and
y coordinate with 8 bit or 16 bit resolution. One channel determines the transition type when fading from
one color to another color.
Source Matching
Select from a list of light sources to match that color and spectrum. Source Matching saves a lot of time
when you need a specific illumination. Select from 50 different light sources the one which fits best to your
demands.
