10 | Error Codes
38 L-SeriesPlus User Manual
10 Error Codes
Code Error Remedy
E.003 Controller over temperature.
STATUS LED lit up red.
Let the L-Series Plus cool down.Turn the dimmer knob to
„0“ or send an intensity value „0“ via DMX to start the light
engine(s) again.
E.004 Light engine over
temperature
See E.003
E.005 Missing LED supply. The LED power supply is faulty. Contact the ARRI service.
E.006 Calibration data of light
engine faulty or EEPROM
error.
WARNING: Loss of calibration data. This error can only
be fixed by re-calibrating the light engine. Please contact
the ARRI service.
E.007 Invalid PWM value calculation Notice: The L-Series Plus can be used on. This message
is more a notification than an error.
E.008 Invalid values during
calculation
See E.007
E.009 Invalid values during
calculation
See E.007
E.010 Fan error. The fan speed
deviates or the fan doesn’t
run at all.
All mechanical tests or repairs may only be carried out by
a trained service technician.
E.011 Fixture menu not detected. If the fixture menu is working, error E.011 can be ignored.
However, if the fixture menu remains dark (no LED lights
up) we recommend to contact the ARRI service. They can
then carry out detailed analyses.
E.012 Temperature sensor(s) are
defective or deviation within
NTC values too high.
One or more temperature sensors are defective or the
deviation within the individual NTCs or BNTCs exceeds
the variation tolerance of 12° C / 54° F.
E.013 Calibration data faulty. WARNING: Loss of calibration data. Fixture needs to be
re-calibrated.
E.014 Watchdog error Notice: The L-Series Plus can be used on. This message
is more a notification than an error.
E.015 LED channel faulty Notice: The L-Series Plus can be used on. This message
is more a notification than an error.
E.016 Boost over temperature Let the L-Series Plus cool down. Turn the dimmer knob to
„0“ or send an intensity value „0“ via DMX to start the light
engine(s) again.
E.018 PWM driver not found Turn the L-Series Plus off and on again. If the problem
persists, please contact the ARRI service.
E.020 Update with errors This will be seen if the update process has detected an
error during the update.
E.021 Flash init error. No filesystem
mounted.
This will happen if the flash disc has a problem with its file
system.
E.022 Missing Boost Turn the L-Series Plus off and on again. If the problem
persists, please contact the ARRI service.
E.023 12V Missing The 12V power is missing during startup. Please contact
the ARRI service.
E.024 5V Missing The 5V power is missing during startup. Please contact
the ARRI service.
E.025 DMX Data Collision The fixture detected data on the data line when trying to
send data as a gateway or host fixture. It stops the
gateway and/or host/client mode to avoid further data
collision.
