Creative Functions | 4
L-SeriesPlus User Manual 15
With activated extended color control:
• A star next to the active operation mode indicates the activated extended color control,
• the parameters are stored with each preset. Presets which contain parameters of the extended
color control are marked with a star,
• modifying an extended color control parameter leaves any active preset,
• the calibrated RGBW color space becomes active when the extended color control is activated
via DMX,
• the direct RGBW color space is not available,
• the parameters are applied both to the start and end point of a cross fading,
• the parameters are not applied to lighting effects.
NOTICE
Presets made in Firmware v. 4.0 or higher will not work on previous firmware versions.
4.8 Set the Brightness in all Control Modes
Set the brightness in all control modes continuously with the encoder (4). The setting is dynamic:
Turning the encoder (4) fast changes the intensity in coarse steps, turning it slow changes the
intensity in fine steps.
4.9 Set the Dimming Curve
The L-Series Plus offers four dimming curves. The dimming curves are global: They affect both the
intensity control via the device menu or DMX, wireless DMX, Art-Net and sACN.
• Linear: The intensity changes proportional to the encoder (4) or the channel value.
• Exponential: The resolution is high at lower intensity levels and low at higher intensity levels.
Use this dimming curve when you need a high resolution at low intensity levels. This is the
default setting.
• Logarithmic: The resolution is low at lower intensity levels and high at higher intensity levels.
Use this dimming curve when you need a high resolution at high intensity levels.
• S curve: The resolution is both high at lower and higher intensity levels and low at intensity
levels in between. Use this dimming curve, when you need a high resolution at low and high
intensity levels.
To set the dimming curve
1) Push MENU (10) to open the device menu.
2) Turn and push the encoder (4) to open the menu Light Control > Dimming Curve.
3) Turn and push the encoder (4) to set and start a dimming curve.
NOTICE
The dynamic of an effect using the intensity is very low, when you choose a basic intensity value in a
flat area of the dimming curve. Start a different effect or set another dimming curve to create a more
dynamic effect.
