DMX | 6
L-SeriesPlus User Manual 27
To set the DMX-Signal-Loss Behavior:
1) Push MENU (10) to open the menu.
2) Turn and push the encoder (4) to open the menu DMX Settings > DMX Loss Behavior.
3) Turn and push the encoder (4) to set an option.
4) Push MENU (10) to close the menu.
NOTICE
The setting of the DMX signal loss behavior is part of a DMX preset. The setting can change when
calling up a DMX preset.
6.5 DMX Protocol Version
The L-Series Plus supports different DMX protocol versions. When a channel description is changed
or channels are added, a new version of the DMX protocol is published. To ensure compatibility with
existing DMX installations, you can set the DMX protocol version that the device should use.
To set the DMX Protocol Version:
1) Push MENU (10) to open the menu.
2) Turn and push the encoder (4) to open the menu DMX Settings > DMX Protocol Version.
3) Turn and push the encoder (4) to set the DMX Protocol Version.
4) Push MENU (10) to close the menu.
6.6 DMX Extended Color
The L-Series Plus applies 8 additional parameters to every DMX mode when the extended color
control is started through the DMX settings menu. Depending on the mode, 8 (8-bit modes) or 16
(16-bit modes and Coarse / Fine) additional DMX channels are added per device. Please find more
information in the L-Series Plus DMX Protocol Specification which is available for free download on
the ARRI website www.arri.com.
6.7 DMX Frame Filter
As a default setting, the L-Series Plus checks the integrity of the received control data. If certain
parameters of the data stream (e.g. the number of received DMX channels) change, the device
displays a warning message and checks the data stream again before accepting it as a valid control
signal. If the length of the data stream changes repeatedly, the check may cause unexpected
behavior of the device. Therefore this function can be disabled. The device then accepts all received
control data without further checking.
To Activate and De-activate the DMX Frame Filter:
1) Push MENU (10) to open the menu.
2) Turn and push the encoder (4) to open the menu DMX Settings > DMX Framefilter.
3) Turn and push the encoder (4) to set the option.
4) Push MENU (10) to close the menu.
