Device Menu | 2
L-SeriesPlus User Manual 11
DISPLAY (9)
The display shows the current settings and other information during normal operation. Press MENU
(10) to open or close the menu. Use the encoder (4) and BACK (11) to navigate through the menu.
MENU (10)
MENU opens the device menu. Press MENU when the menu is open to close the menu and abort
an action (Escape). Use the encoder (4) to scroll through the menu, open sub menus and set
parameters.
Press MENU long to display the menus which are used most.
Back (11)
The BACK button closes a sub menu and aborts an action (Escape). Compared to the MENU button
(10) the BACK button only closes the sub menu, but not the fixture menu.
Press BACK long to display the last used menus.
To lock the device menu
Use the feature to prevent an accidental change of settings.
1) Press the encoder (4) in the home screen for 5 seconds to lock all buttons and knobs.
2) The word LOCKED appears on the display when locked.
3) Press the encoder (4) in the home screen for 5 seconds again to unlock all buttons and knobs.
2.3 To Set the Operation Mode
Press MODE (8) short to switch from CCT to HSI to GEL to Source to RGBW to x, y and back to
CCT mode.
In CCT mode the L-Series Plus generates white light with optimized color rendition. In HSI mode the
L-Series Plus generates colored light. If saturation is set very low, the L-Series Plus generates white
light, but not with optimized color rendition. The GEL mode offers an extensive color gel library. In
Source mode the L-Series Plus generates the light of traditional light sources. Use the RGBW mode
to generate a RGBW color using the control panel. The x, y mode generates a color defined by its x,
y coordinates.
Press MODE (8) long (> 3 sec.) to start the extended color control. The extended color control
feature is not available in RGBW mode unless RGBW Calibrated Color Space is started.
2.4 Remote Control Panel
The L-Series Plus Remote is connected with an USB cable to the device. It is powered by the L-
Series Plus and does not use a battery. The L-Series Plus Remote emulates the L-Series Plus
device menu. Each L-Series Plus Remote controls one L-Series Plus.
Use multiple devices in a host / client configuration to control them with one Remote Control.
The L-Series Plus checks the firmware of the Remote Control every time it is connected. If the
firmware version of the Remote Control is different to the firmware version of the L-Series Plus, the
Remote Control firmware will be synchronized automatically, no matter if it is an upgrade or
downgrade.
