10
GB
connecting it to the power supply to switch it on. The same
applies if the appliance is moved afterwards.
• If the appliance has been switched off or disconnected from
the power supply, it is necessary to wait 5 minutes until
switching on again.
• WARNING! Do not place extension cords with multiple out-
lets or any type of external power supply on the back of the
appliance.
• No other appliances should be plugged into the same socket
as with this appliance.
• Do not attempt to climb onto the appliance.
Intended use
• This appliance is intended to be used in household and simi-
lar applications such as:
- staff kitchen areas in shops, offices and others working en-
vironment;
- farm houses;
- by clients in hotels, motels and other residential type en-
vironment;
- bed and breakfast type environment.
• The appliance is designed for wine storage and cooling. (e.g.
Champagne, white wine , red wine, etc.) Any other use may
lead to damage to the appliance or personal injury.
• Operating the appliance for any other purpose shall be
deemed a misuse of the device. The user shall be solely liable
for improper use of the device.
Grounding installation
This appliance is classified as protection class I and must be
connected to a protective ground. Grounding reduces the risk
of electric shock by providing an escape wire for the electric
current.
This appliance is fitted with a power cord with grounding plug
or electrical connections with grounding wire. The connections
must be properly installed and grounded.
Main parts of the product
(Fig.1 on page 3)
1. Bottle storage cavity
2. Glass window
3. Control panel
4. Cover
Remark: The content of this manual applies for all listed items
unless specified otherwise. The appearance may vary from the
shown illustrations.
Circuit diagram
(Fig.2 on page 3)
A1. Compressor
A2. Ventilation fan out
A3. Solenoid valve
A4. PCB board
A5. Sensor
A6. Sensor
A7. Heater
A8. Heater
A9. LED
A10. Display board
Control panel
(Fig.3 on page 4)
5. ON/OFF power button
• In the standby mode: press 3 seconds, the power is turned
on, the whole machine starts.
• In the power-on state: press the power button, window 5
shows the countdown 3 2 1, the power is turned off, keep
pressing the power button until countdown is finished.
6. Lamp button
• Light color can be changed by single press. Light will be
turned off by long press for 3 seconds.
7. Temperature setting for left zone
• setting temperature: 3-18ºC
8. Temperature setting for right zone
• setting temperature: 3-18ºC
9. Current temperature setting display for left zone
• Display current temperature setting
10. Current temperature setting display for right zone
• Display current temperature setting
Preparation before use
• Remove all protective packaging and wrapping.
• Check that the device is in good condition and with all ac-
cessories. In case of incomplete or damaged delivery, please
contact the supplier immediately. In this case, do not use the
device.
• Clean the accessories and the appliance before use (See ==>
Cleaning & Maintenance).
• Make sure the appliance is completely dry.
• Place the appliance on a horizontal, stable and heat resistant
surface that is safe against water splashes.
• Keep the packaging if you intend to store your appliance in
the future.
• Keep the user manual for future reference.
NOTE! Due to manufacturing residues, the appliance may emit
a light odor during the first few uses. This is normal and does
not indicate any defect or hazard. Make sure the appliance is
well ventilated.
Operating instructions
• Plug in and switch on the cellar by pressing on the power
button for a few seconds.
• When you use the wine cellar for the first time (or restart
the wine cellar after having it shut off for a long time), there
will be a few degrees variance between the temperature you
have selected and the one indicated on the LED readout. This
is normal and it is due to the length of the activation time.
Once the wine cellar is running for a few hours everything
will stabilize.
IMPORTANT: If the unit is unplugged, power is lost, or turned
off, wait 3 to 5 minutes before restarting the unit. The wine
cellar will not start if you attempt to restart before this time
delay.
• These wine cellars reproduce the ideal conditions for wine
storage, at a constant recommended temperature of 12ºC.
They can also be set to provide ideal serving temperature
for full enjoyment of the wine’s qualities. Unless stated by
the wine maker on the bottle, we recommends 7ºC for your
champagne, 12ºC for whites and 18ºC for reds. (Refer to “Op-
timal Wine Serving Temperature”)
• The appliance is designed with “Auto-cycle” defrost system.
