Installation Manual

Page | 15 support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

SurroundVideo® Omni SX

3. Remove the dome cover and set aside. Remove the protective foam and discard.

4. If mounting the camera outside or in a wet environment, thread the camera cable through the

hole on the supplied rubber gasket and align with the three holes on the top of the housing.

Ensure the gasket is properly seated flush with the camera housing.

Figure 2: Mount the Surface mount to the wall or ceiling using the three holes on the housing

NOTE: If you use the side connection of the NPT port, remove the cap covering the side

entrance, otherwise; leave the cap in place. If using the NPT port, always use Teflon tape

around the threads to ensure proper sealing. The conduit fits ¾” NPT standard. Ensure NPT

port is facing downward.

5. Using the three holes on the top of the camera housing, use the supplied screws and attach to

the mounting surface.
