!! ! Installation!Manual!

Page | 9 support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

SurroundVideo®!G5

In-ceiling Mount

To properly flush mount the SurroundVideo® G5 to a drop ceiling or similar surface, a flush mount

adapter kit (SV-FMA) is required (sold separately). An in-ceiling mount should only be attached onto

hard ceilings including wood, plastic, metal and concrete.

1. Cut a hole in the ceiling using the template provided to fit the camera housing.

NOTE: SurroundVideo® G5 ships with both surface mount and in-ceiling mount, the mounting

template takes both into consideration.

2. Loosen the four (4) machine screws with user-supplied #2 Phillips head screwdriver and remove

the in-ceiling mount housing from the surface mount housing (see Figure 4). Set surface mount

housing aside for future use.

Figure 3: Remove four (4) screws

NOTE: The above removed screws are also used to attach the camera with in-ceiling mount

housing to the pendant mount and wall mount. Do not discard.
