!! ! Installation!Manual!

Page | 29 support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

SurroundVideo®!G5

Connecting Heater and Blower

The heater and blower are integrated to the camera. If the heater is required, connect the heater’s

power input to a separate 12-35V DC, 24V AC power supply.

Power Input for Heater

Power

Consumption

12-35V DC, 24V AC (separate power required)*

11W Max(DC)

13W Max(AC)

*Products!shipped!before!6/1/16!will!only!support!10V!to!35V!DC!

Temp Heater

Turns On

Temp Heater Turns Off

Heater*

62.6°F (17° C)

86° F (30° C)

*Heater!must!be!powered!separately;!Blower!is!powered!via!PoE!and!is!always!on!

Color

+ / –

Red

Blue

–

1. Align the holes in the camera with the prepared holes on the mounting surface. Attach the

camera with the in-ceiling mount housing to the surface mounting housing.

2. Insert camera with in-ceiling mount into hard ceiling with the wood screws or any optional

hardware suitable for the mounting surface.
