!! ! Installation!Manual!
Page | 25 support@arecontvision.com
!
!
!
+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com
SurroundVideo®!G5
Adjusting the Pan, Tilt and Focus
1. Remove the dome cover by loosening the captive fasteners with the supplied Philips head
screwdriver.
2. Power on the camera to adjust the pan, tilt and focus.
3. To adjust the pan, use a #2 Phillips screwdriver to loosen both screws on the sides of the plastic
gimbal bracket as shown in Figure 18.
Figure 18: Loosen both screws aside of gimbal bracket
4. Adjust the pan as required and re-tighten the screw (Figure 19).
!
Figure 19: Adjust the pan and re-tighten the screws
Reference #
Description
1
Adjustable 360°
