!! ! Installation!Manual!
Page | 9 support@arecontvision.com
!
!
!
+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com
MicroDome®!G2
Figure 6: Attach dome cover with captive fasteners
9. If using the MCD-4S accessory plate, tighten the two captive fasteners with the supplied Philips
head screwdriver to secure the dome cover to the user supplied 4S junction box. Tightly insert
the two black plugs supplied with the MCD-4S for the remaining open holes. Cut any excess off
the rubber plugs, flush against the dome cover, with a utility knife.
Figure 7: Attach the MCD-4S accessory plate to the user supplied 4S junction box
NOTE: The supplied security torx screws may also be used.
