2 Installation Manual

Page | 7 support@arecontvision.com

Optional: Connecting Digital I/O:

9. To use digital I/O, connect digital I/O with

pigtail cable connector as shown in Image

NOTE 1: MegaView

2 only supports digital

input but no digital output.

NOTE 2: Table 1 shows electrical

characteristics

Electrical

Characteristics:

Min

Max

Input voltage (V)

(measured between

+ and – terminals)

2.9

6.3

OFF

1.3

OFF

0.1

Table 1

NOTE 3: The digital input is electrically isolated

from the rest of the camera’s electrical circuitry

via general-purpose photo couplers. The input

is additionally protected with a serial 250 Ohm

resistor, and a debouncing circuit. Duration of

any input signal should be at least 5 ms to

comply with the requirements of the debouncing

circuit.

NOTE 4: Table 2 shows cable color for digital

input

Green

Digital IN +

Black

Digital IN -

Table 2
