Page | 30 support@arecontvision.com
+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com
Camera Power Up
This product should be installed by a qualified service technician in accordance with the
National Electrical Code (NEC 800 CEC Section 60) or applicable local code.
1. Connect the camera to a PoE port on 100Mbps network PoE switch using an Ethernet cable as
shown in the image below.
Reference #
Description
1
PoE Connector
NOTE: Recommend to route the Ethernet cable as shown in the image below
2. If the camera is powered by an outside power supply, 12-24 VDC, connect the power cable.
3. Connect the PoE switch to your computer’s network port using an Ethernet cable.
