! ! Installation Manual
!
Page | 17 support@arecontvision.com
!
!
!
+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com
MegaDome
®
G3 RS
6. Prepare the network cable with the supplied grommet and insertion tool as shown in Figure 3.
Figure 3
NOTE: When mounting the camera outdoors or in a wet environment, use of supplied grommet
is recommended. Ensure the grommet is properly seated flush with the camera housing.
7. Align the hole on MegaDome
®
G3 RS camera with the hole on mounting plate, and install the
grommet on camera housing as shown in Figure 4.
!!!!!!!!!
Figure 4
8. Fasten securely four captive screws as shown in Figure 5.
!!!!!!!!!!
Figure 5
