Installation Manual

Page | 26 support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MegaDome

Auxiliary I/O Functions

The auxiliary input and output are accessible after removing dome cover.

Reference #

Description

Input (White + / Black -)

Output (Orange + / Yellow -)

NOTE: MegaDome

G3 camera supports digital input and digital output. See Table 1 for electrical

characteristics.

Electrical Characteristics

MIN

MAX

Input Voltage (V)

(Measured between +

and – terminals)

3.5

6.3

OFF

1.3

Output Current (mA)

(Measured between +

and – terminals)

Applied Voltage

Range: 0-80V

OFF

0.1

Table 1

NOTE: The digital input is electrically isolated from the rest of the camera’s electrical circuitry via

general-purpose photo couplers. The input is additionally protected with a serial 250 Ohm resistor, and

a de-bouncing circuit. Duration of any input signal should be at least 5 ms to comply with the

requirements of the de-bouncing circuit.

NOTE: Table 2 shows the cable color for digital input and output.
