Handleiding

ConteraIP

Bullet EX Megapixel Camera

ConteraIP

Bullet EX | Installation Manual

Surface Mount

The ConteraIP

Outdoor Dome EX camera can be directly attached onto hard ceilings or walls including

wood, plastic, metal and concrete.

1. Use the template, anchors, and screws provided to prepare the mounting provisions for the

camera installation.

2. Use the supplied security L-key, to loosen the four (4) tamper resistant screws securing the dome

cover. Do not remove screws from the dome cover.

3. Remove the protective foam and discard.

4. Install four supplied dry wall anchors using the supplied mounting template.

5. Align four supplied screws (4pcs #8-16 1¼” tapping screws) with the dry wall anchors and screw

mounting plate into place.

6. Prepare the network cable with the supplied grommet and insertion tool.

NOTE: When mounting the camera outdoors or in a wet environment, use of supplied grommet

is recommended. Ensure the grommet is properly seated flush with the camera housing.
