Page 14 of 54

Figure 2: Attach wall mount adapter to pole mount adapter

Reference #

Description

Steel straps with compression screws

AV-WMJB-W wall mount

SO-CAP-W mount cap

Conduit

AV-PMA-W pole mount

AV-JBA-W Junction box

Apply Teflon water seal tape to the thread of ¾” NPT pipe to avoid water leakage

7. Use the supplied two Steel Straps to attach the Pole Mount Adapter to the pole and tighten the

compression screws as shown in Figure 2.

8. Attach the camera to the Wall Mount Adapter.

9. To configure the camera, reference the camera discovery, set-up and configuration section.
