Page 22 of 54
Aligning the Cameras
Properly aligning each camera is essential during setup. Each camera must be placed in a clockwise
sequence on the circumference of the track to ensure proper viewing of each camera.
Figure 1: Place cameras in clockwise position on the track
When positioning the sensors, ensure the conduit mounting hole does not obstruct the cable when
positioning the sensor.
Reference #
Description
1
Sensor 1
2
Sensor 2
3
Sensor 3
4
Sensor 4
