Page 16 of 54
Figure 2: Attach corner mount adapter to exterior corner wall
Reference #
Description
1
Attach corner mount adapter to exterior 90° corner wall
2
AV-WMJB-W wall mount
3
SO-CAP-W mount cap
4
Conduit
5
AV-CRMA-W corner mount adapter
6
AV-JBA-W Junction box
7
Apply Teflon water seal tape to the thread of ¾” NPT pipe to avoid
water leakage
7. Using the screws provided (or other hardware), attach the Corner Mount Adapter to an exterior
90° corner wall.
8. Attach camera to Wall Mount Adapter.
9. To configure the camera, reference the camera discovery, set-up and configuration section.
