Page 14 of 45

Camera Power Up

1. Connect the camera to a PoE port on 1000Mbps network PoE switch using an Ethernet cable.

2. If the camera is powered by an external power supply 12-48V DC or 24V AC must be supplied.

NOTE: This product is intended to be supplied by a Listed Power Adapter or DC power source, rated

(1) 24 VAC, 50/60Hz, (Max. 10.5W); (2) 12VDC, (Max.10.5W); (3) 48VDC, (Max. 9.5W) for PoE, Tma

= 50ºC, and the altitude of operation = 2000m. If need further assistance with purchasing the power

source, please contact AV Costar for further information.

Ensure the power cord connection of the power adapter to a socket-outlet with an earthing

connection.

3. Connect the PoE switch to your computer’s network port by using an ethernet cable.

LED

Status

Description

Green

Quick Flashing

Link has been established

Slow Flashing

Normal operation

None

No Connection
