Page 5 of 54
Installation
In-ceiling (-F Model) Installation
1. Determine a secure location to mount the camera. Cut a hole in the ceiling
using the template provided (3.25 inches in diameter) to fit the camera
housing.
2. Remove the dome cover from the camera by unscrewing the captive fastener.
3. Pull the network cable through the ceiling and plug it into the network connector on
the camera housing (Note: this can be done at a later time if there is access to the
network connector on the camera housing after installation into the ceiling).
4. Check that the indicator LED’s are illuminated to the desired conditions (see LED
Indicator table).
5. Push the three spring actuated retention arms to the upward position as shown in
the diagram.
Reference #
Description
1
Captive Fastener
2
Dome Cover
3
Camera Head
