Camera Power Up

1. Connect the camera to a PoE port on 100Mbps network PoE switch using an Ethernet cable.

SURFACE MOUNT (IR-S Model) FLUSH MOUNT (-F Model)

NOTE: This product is intended to be supplied by a Listed Power Adapter

or DC power source, rated 48VDC, (Max. 7.2W) for PoE, Tma = 50ºC, and the altitude of

operation = 2000m. If need further assistance with purchasing the power source,

please contact AV Costar for further information.

Ensure the power cord connection of the power adapter to a socket-outlet with an earthing

connection.

2. Connect the PoE switch to your computer’s network port by using an ethernet cable.

LED

Status

Description

Green

Quick Flashing

Link has been established

Slow Flashing

Normal operation

None

No Connection
