ConteraIP

Bullet EX Megapixel Camera

ConteraIP

Bullet EX | Installation Manual

6. Use the supplied two Steel Straps to attach the Pole Mount Adapter to the pole and tighten the

compression screws.

7. To configure the camera, reference the camera discovery, set-up and configuration section.

Electrical Box Adapter

The electrical box adapter is used to attach the camera to a common single, double or square electrical

box. The AV-EBAS is required (sold separately).

1. Using the supplied machine screws, match the mounting holes on the electrical box adapter with

the threaded holes on the electrical box. Ensure every threaded hole is matched with a mounting

hole.

2. Attach the electrical box adapter to the user supplied electrical box.

Reference #

Description

1 Steel straps with compression screws

2 AV-JBA-W junction box adapter

3 ConteraIP

Bullet EX Camera

4 Conduit pipe

5 AV-PMA pole mount adapter

6 Apply Teflon water seal tape to the thread of ¾” NPT pipe to

avoid water leakage
