AQUASURE HARMONY SERIES

2. Push the brine line into the brine

line connector and make sure it goes

through the o-ring. Secure by pushing

in the locking clip. Pull the brine line to

see if it is secure.

1. Connect the brine line to the control

valve by removing the blue locking clip

on the brine line connector.

IMPORTANT! Make sure the brine line is secure to the elbow quick connection inside the brine

well. If the connection is not secure and sealed, it may not be able to perform a proper system

regeneration when needed, and can potentially cause overll and result in leaks.

STEP 4. Connecting the Brine Tank

3. Open the easy-ll lid on the front of the softener

housing and remove the white cap on the top of

the brine well.

4. Insert the brine line through the upper hole on

the right side of the softener housing and then

through the adjacent hole on the brine well.

5. Push the brine line into the quick connect tting

inside the brine well and give it a tug to make sure

it is thoroughly seated in the quick connection.

6. Replace the white cap and pour in 80 lbs (two

bags) of course grade salt and 5 gallons of tap

water into the brine tank.

7. LIFT TO CLOSE the easy-ll lid.
