3
www.AQUASUREUSA.com
Tel: 1-800-661-0680
I. System Review and Installation Tools
Please take the system and all the components out of the box. Inspect the system and all the
connection ttings carefully and make sure nothing was damaged during shipping. If any part is
cracked, broken, or missing, please do not proceed with the installation. Contact Aquasure support or
your distributor for a diagnosis or exchange.
INSPECTION & PREPARATION
System Components
1. Digital Control Valve
2. Upper Distribution Basket
3. Resin Tank
(Pre-lled)
4. Riser Tube & Bottom
Distribution Basket
(Pre-installed)
5. Thin Prole Hydraulic Meter
6. High Strength Bypass Valve
7. 1” Yoke Connection
(3/4” Available on request)
8. Brine Tank Lid
9. Grid Plate
10. Brine Tank
11. 6’ of 3/8” Brine Line
12. 10’ of 1/2” Drain Line
13. Power Adapter
14. Brine Well
15. Float Valve
16. Brine Drain Connection
Required Tool List for System Installation
• Channel Locks
• Screwdriver
• Plumber’s Tape
• Utility Knife
• Two Adjustable Wrenches
• Use 1”
(Or 3/4” Depending on system) copper, brass,
or PEX pipe and ttings. Some codes may
also allow PVC plastic pipe.
• Silicone Grease (Lubricant)
• Please note modication to home plumbing
may require the use of additional tools.
Required Components not Included with the System
• 80 lbs Extra Course Grade Salt Pellets are needed to ll the brine tank. The softener
system will use any kind of salt formulated for water softener use, but it is advised to use the
pellet-shaped salt as it tends to dissolve more evenly.
(Potassium can be used for a salt-free alternative)
Preassembled Preassembled
Preassembled
1
2
4
5 6 7
8
9
10
11
12
13
14
15
3
