* Damage to the Lamp Head or Control Box from moisture is not covered under the warranty.
If the STORM 1200x is used in a heavy rain, it is recommended to use the tilt angle range of
the lamp head as shown below:
32
Product Specifications
+45°
-45°
Power Consumption (Max) 1450W Output Power (Max) 1200W
Voltage Input Range
100
240 VAC
Operating Current 6-15.5A
Cooling Method Air Cooling Operating Temperature -20°C ~ 45°C
Color Temperature
2500 K
10000 K
Weather Resistance Rating IP65
CQS(5600K) 96 CQS(3200K) 97
SSI(D56) 87 SSI(D32) 87
CRI 95+ TLCI 95+
TM-30 Rf (average value) 95 TM-30 Rg (average value) 100
Control Methods
On-board, Sidus Link & Sidus Link Pro Apps,
DMX/RDM, CRMX, sACN/Art-Net
Bluetooth Wireless Range ≤ 100 m CRMX Wireless Range ≤ 100 m
Size
(length x width x height)
Lamp Head
(without yoke)
33.46 x 23.17 x 25.08cm /
13.17 x 9.12 x 9.87 in
Lamp Head
(with yoke)
3
3.46 x 33.8 x 55.73cm /
13.17 x 13.31 x 21.94 in
Control Box
13.58 x 20 x 34.35cm /
5.35 x 7.87 x 13.52 in
Weight
Lamp Head 9.8 kg/21.6lbs
Control Box 6.12 kg/13.5 lbs
