13. Connecting the INFINIMAT(s) to the Control Box 1600W
a. 1x2 (100W), 1x4 (200W), 2x4 (400W), 4x4 (800w) and 8x8 (1600W) INFINIMATs are com-
patible
with the Control Box 1600W.
b. Example output possibilities on the Control Box 1600W include:
i. 1 X 1600W
ii.
2x800W
iii. 1 x
800W
and 2 x 400W
iv. 1 x 200W and 2 x 100W
v.2x200W
vi.1 X400W
On the Control Box 1600W, there are 5 output ports in total:
(2)
1600W Head Cable ports (the
D and E ports) and (3) 400W Head Cable ports (A, B, C ports). Upon inserting a lamp's head
cable, the wattage is automatically recognized, and the corresponding Power Indicator Light
will illuminate. Power is supplied sequentially through interfaces A-B-C-D-E. The Control Box
can recognize the wattage of the lamp and determine if it can meet full power output. If not, it
assesses if half-power output is feasible; if so, it proceeds with half-power output. If the Con-
trol Box has no more power available to distribute, then it recognizes the lamp but refrains
from outputting.
Separate
indicator lights are provided to
recognize the power
of
different lamp bodies.
GREEN
Full-Power for the INFINIMAT connected to this port.
YELLOW
Half-Power for the INFINIMAT connected to this port.
RED
Not enough Power for the INFINIMAT model connected to this port.
OFF
No INFINIMAT detected on this port.
24
